Building from source

Building software can be tricky, but hopefully this won’t be - thanks to Gradle.

Note

Do you need this?! Most people using QuPath won’t need to build QuPath from source! Just download an existing installer from qupath.github.io and use that instead.

Command line

If you’re moderately comfortable working from a command line, there’s not much required to build QuPath:

  1. Install git, e.g. from https://git-scm.com

  2. Install OpenJDK 17, e.g. from adoptium.net

  3. Open a command prompt in an empty directory and run the following:

git clone https://github.com/qupath/qupath
cd qupath
gradlew clean jpackage
git clone https://github.com/qupath/qupath
cd qupath
./gradlew clean jpackage

It will take a few minutes to download everything required and build the software. If all goes well, you should see a triumphant message that the build was successful.

../../_images/building-success.png

That’s it! You can find QuPath inside the ./build/dist/ subdirectory.

Which Java version do I need?

If you already have Java installed, you might be able to skip Step 2. Most Java versions >= 8 should work to launch Gradle, which will then automatically download the version it needs. However, since QuPath currently requires OpenJDK 16, we recommend just installing that and saving Gradle the extra effort.

Note that some problems have been reported using a version of OpenJDK based on OpenJ9, such as may be provided by some package managers. Switching to an OpenJDK distribution based on HotSpot may help – see here for details.

Customizing the build

Creating installers

If you need to create an installer for QuPath, you can use

gradlew clean jpackage -P package=installer
./gradlew clean jpackage -P package=installer

Note that for this to work on Windows you’ll need to install WIX Toolset.

Adding GPU support

A common question is whether QuPath uses a GPU to accelerate processing. The answer, currently, is ‘no’.

However, it is possible to build QuPath with support for CUDA via OpenCV and JavaCPP by using the -Pcuda or -Pcuda-redist options.

gradlew clean jpackage -Pcuda-redist
./gradlew clean jpackage -Pcuda-redist

You should use -Pcuda if you want to use your own CUDA installation (which needs to be the correct version to match JavaCPP’s OpenCV distribution), and -Pcuda-redist if you want to download the necessary files automatically. Before doing so you should check out the licensing terms for CUDA at https://github.com/bytedeco/javacpp-presets/tree/master/cuda

Two important things to note are:

  • This only works on Windows or Linux with recent NVIDIA GPUs and drivers

  • Currently, only StarDist is likely to see any benefit (no other QuPath code explicitly uses the GPU)

Building a specific version

QuPath releases are associated with different git tags. You can get the code associated with QuPath 0.4.0 by using the command

git checkout tags/v0.4.0 -b v0.4.0

You can then try building it as above, however note that some different versions may require different build commands (e.g. the steps for v0.2.3 are slightly different from v0.3.0). Check out the docs associated with the specific version if this is the case.

Other options

A few other ways to obtain and/or build QuPath’s code are described below. These might be better if you a) don’t like the command line much, or b) want to make changes to the software.

GitHub Desktop

If you’re using either Mac or Windows, GitHub Desktop provides a friendly way to get the QuPath code. The main steps are

../../_images/building-clone.png

You can now open a command prompt in the correct directory directly from GitHub Desktop by choosing Repository ‣ Open in Command Prompt.

Installing Git or not?

At this point you may be asked if you want to install Git.

You don’t have to (I think…), but if you do then you’ll be ask a lot of questions during the installation. One of them is to choose a text editor, where you can select Atom.

Finally, the command needed to build QuPath is then the same as above:

gradlew clean jpackage
./gradlew clean jpackage

Updating the code

Once you’ve built QuPath once, updating it to use the latest source code in GitHub Desktop should be easier. The right-most button on the main toolbar serves two purposes: to Fetch information about the latest changes (from GitHub) and to Pull the changes down to your computer.

../../_images/building-branches.png

If the option is Fetch origin, when you press the button the text will switch to Pull origin if any changes are available, with info about the number of changes.

You can press it again to pull those changes, and then rebuild QuPath using gradlew.

../../_images/building-pull.png

Download release

You can circumvent the need to use git entirely by downloading the QuPath code associated with a specific release from http://github.com/qupath/qupath/releases

Simply choose the Source code (zip) or Source code (tar.gz) option. You can then build it from a command prompt as described above.

Running from an IDE

You should be able to import QuPath into any IDE (e.g. Eclipse, IntelliJ) that supports Gradle.

Eclipse

I personally use Eclipse for QuPath development, which allows me to run the software in debug mode – and even change the code while it is running.

To do this, first download and build QuPath once as describe above. Then use File ‣ Import… from within Eclipse and select Existing Gradle project.

../../_images/building-eclipse-import.png

After selecting the QuPath directory and importing (usually accepting the default import options is fine), right-click on QuPath.java (the main launch class) as shown below:

../../_images/building-eclipse-launch.png

Now choose Debug As ‣ Java Application from the context menu.

This should launch QuPath, but it will fail to find the native libraries it needs to use OpenSlide. To fix that, use Run ‣ Debug configurations… to adjust the arguments for your configuration as shown below, changing -Xmx if needed to customize the memory available.

../../_images/building-eclipse-config.png

Finally, press the Debug button in the bottom right, and QuPath should launch with OpenSlide intact.

This works because it starts inside the ${workspace_loc:qupath/build/natives} directory, which should contain the OpenSlide native libraries – assuming you have build QuPath at least once before.

You can now use Run ‣ Debug History ‣ QuPath to launch QuPath with the same configuration in the future.

The useful thing about using debug mode is that you can make changes to the QuPath code while QuPath is running and, providing they aren’t too extreme, they will be incorporated into the software without needing to relaunch it.
